15kV Inner Cone Busbar Kits

Name: 15kV Inner Cone Busbar Kits
Brand: Shenzhen Woer Electric Technology Co., Ltd

Inner cone busbar kits are suitable for the combined connection of ring main units to supply more branches for extension. Meanwhile, it is a prior option to combined ring main units. The voltage class of his type of Inner cone busbar kits are 15kV, consisting of Inner cone busbar insulator, inner cone busbar connector and inner cone busbar plug.

 Get a Quote

Specification of 15kV Inner Cone Busbar Kits

Item	Inner Cone Busbar Kits
Voltage Class	15kV
Rated Current	630A
AC Withstand Voltage	48kV for 1min
Partial Discharge	15kV, ≤10pC
Impulse Withstand Voltage (10 times for each polarity)	95kV
Screen Resistance	≤5000Ω
Temperature Rise	≤65K

Features of 15kV Inner Cone Busbar Kits

Perfect insulation.
