Busbar Connector up to 40.5kV 1250A

Name: Busbar Connector up to 40.5kV 1250A
Brand: Shenzhen Woer Electric Technology Co., Ltd

Busbar Connector is mainly used in SF6 insulated Switchgears, to mate with the type C bushing interfaces. This type of busbar connector is screened busbar up to 40.5kV 1250A. Unscreened products for busbar connector system are also available.

 Get a Quote  PDF Download

Specification of Busbar Connector up to 40.5kV 1250A

Item	Busbar Connector and Kits
Voltage Class	40.5kV
Rated Current	1250A
AC Withstand Voltage	95kV for 1min
Partial Discharge	45kV, ≤10pC
Impulse Withstand Voltage (10 times for each polarity)	200kV
Screen Resistance	≤5000Ω

Features of Busbar Connector up to 40.5kV 1250A

Variable busbar length from 550mm 600mm 700mm and 800mm available.

Quick and easy assembly.

Screening by outer conductive layer.

Intergrated stress control system.
