For 15kV 200A Elbow Connector installed on wire shield cable, the Cable Shield Adapters, made of EPDM rubber, provide both sealing protection against moisture ingress and an easy grounding for cable wire.
| Spec. | Dimension over cable insulation | |
| inch | mm | |
| ф12 | 0.53~0.68 | 13.5~17.3 |
| ф15 | 0.64~0.82 | 16.3~20.8 |
| ф18 | 0.76~0.95 | 19.3~24.1 |
| ф20 | 0.85~1.05 | 21.6~26.7 |
| ф23 | 0.98~1.18 | 24.9~30.0 |
| ф26 | 1.03~1.31 | 27.7~33.3 |
| ф29 | 1.18~1.46 | 30.0~37.2 |
| ф32 | 1.37~1.63 | 34.8~41.4 |
| ф35 | 1.52~1.78 | 38.6~46.2 |
The product provides a sealed and waterproof device.
When the cable shield is grounded, this device eliminates the need for soldering and tape wrapping, simplifying the installation process.
The material is made of high-quality EPDM rubber.
Its compact structure better meets the trend in enclosure design.
