WOER self-adaptive weathering resistance & water proofing tape is used for waterproofing and insulation and enhance electriccal products' insulation and avoid electrical incidents caused by aged electrical products, to eventually improve insulation in power distribution network. It can be also used to water-proofing protection for telecommunication equipments.
| No. | Item( Before cured) | Typical value | ||
| 1 | Use in_ after unpack | 30min | ||
| 2 | Fully cured | 7d | ||
| 3 | Product packed in | tape | ||
| 4 | Color | red, yellow, green, black | ||
| 5 | Item (After cured) | |||
| 6 | Hardness Shores A | 49 | ||
| 7 | Tensile strength /MPa | 1.75 | ||
| 8 | Elongation at break % | 370 | ||
| 9 | Dielectric strength kV/mm | 36.17 | ||
| 10 | Volume resistivity 0 cm | 1.41X 10¹⁵ | ||
| 11 | Dielectric constant | 3.08 | ||
| 12 | Dielectric loss | 0.0014 | ||
| 13 | Flame retardant grade | V1 | ||
| 14 | Water proof and voltage withstanding test(20kV, 4 h) | pass | ||
| 15 | Storage Duration | 1 year | ||
Product size:
Product dimension: 600mm×90mm×1.8mm
1000mm×90mm×1.8mm
170mm×120mm×1.8mm
Remark: Customization is available for request.
Cured when exposed to air.
Easy to install without special tools especially high above the ground.
Good UV resistance and reliable adhesion.
Quick self-fusing upon stretching and excellent water proofingin.
Refine and even composition makes better insulation performance.
